• Get the depth data via USB to display the point cloud image and pseudo color image;
  • Capture the depth images and video.
  • Use mouse to rotate and zoom the point cloud images.
  • Control the TOF camera working mode: Mono-frequency or Multi-frequencies;
  • Control the frame rate of the TOF camera;
  • Control the exposure time of the TOF camera.
Depth sensor:
1 / 3.5 inch CMOS
RGB sensor:
1/3 inch CMOS
IMU:
Bosch
Viewing angle:
60° (H) × 45 ° (V)
Depth Resolution:
224x172(38k)
RGB Resolution:
2688 x 1520
Detection accuracy:
≤1% of distance (0.5m-4m @5fps)
≤2% of distance (0.1m-1m @45fps)
Detection range:
0.1m-4m
Frame rate:
5-45fps
Operation wavelength:
850nm
Power/Data transmission:
Standard USB3.0 / 2.0 interface
Hardware platform:
Movidius MA2155B
Operation system:
Windows, Linux
Depth sensor:
1 / 3 inch CMOS
RGB sensor:
1/6 inch CMOS
Viewing angle:
65° (H) × 52 ° (V)
Depth Resolution:
Up to 1280*1024@60fps
RGB Resolution:
1280*1080
Detection accuracy:
1mm @ 1m
Detection range:
0.5m to 5m
Frame rate:
30fps
Operation wavelength:
825±5nm@25°C
Power/Data transmission:
USB 2.0 interface
Hardware platform:
ASIC
Operation system:
Windows, Linux
